Professional 3D Scanner 3DeVOK MT
Features
Fast and Stable Scanning
Artistic Design
Reverse Engineering
Human Digitization
Specification
| Light Source | 34 Blue Laser Lines | 22 Infrared Laser Lines | Infrared VCSEL Structured Light |
|---|---|---|---|
| Laser Glass | CLASS II (eye-safe) | CLASS I (eye-safe) | |
| Scan Mode | Crossed Blue Lasers | Crossed Infrared Lasers | Infrared Linear-array Sctructured Light-Speckle |
| Accuracy | Up to 0.025mm/0.00098'' | ||
| Scanning Rate | Up to 3,300,000 Points/s | Up to 2,450,000 Points/s | Up to 4,500,000 Points/s |
| Scanning Distance | 150-1000mm/5.91-39.37'' | 150-1500mm/5.91-59.1'’ | |
| Object Size | 100–8000 mm/3.94-315'’ | ||
| Resolution | up to 0.02mm/0.0008'’ | ||
| Power Source | DC:12V,5.0A | ||
| Output formats | .stl, .ply, .obj, .igs, wrl, .xyz, .dae, .fbx, .ma, .asc or customized | ||
| Dimension/Weight | 215x73x53mm/8.46x2.87x2.09'’ 620g/1.37lbs | ||
| PC Configuration | OS: Win10/Win 11, 64-bit; CPU: i7-13650HX and Above; RAM: 32GB and above; Graphic Card: NVIDIA discrete, NVIDIA RTX3060 and above | ||
