Professional-Grade Color 3D Scanner Ireal M3
Features
Adaptability to Dark and Light Colors
Human Body Scanning
Art and Desgin
Better Material Adaptability
Specification
| Light Sources | Infrared Parallel Laser Lines | Infrared VCSEL Structured Light |
|---|---|---|
| Technology | 7 Infrared Parallel Laser Lines | Infrared Linear-array Structured Light (Speckle) |
| Visibility | Invisible | |
| Safety of Lasers | EN 60825 Class I Certificate (Eye-safe) | |
| Safety of LED Lighting | EN 62471 Photobiological Safety Certificate | |
| Ability to Capture Texture | Yes | |
| Rapid Scan Mode | / | Feature/Mixed/Texture Alignments |
| High-accuracy Scan Mode (on Object) | Markers Alignment | |
| Human Body Scanning | / | With Four Highlights |
| Scanning Range | Optimal Scanning Distance: 400 mm Optimal Scanning Distance Range: 300-650 mm Effective Scanning Distance Range: 280-1000 mm | |
| Max. Field of View | 400 x 240 mm | 580 x 550 mm |
| Recommended Object Size | 0.05-4 m | 0.3-4 m |
| Max. Scanning Speed | Up to 60 FPS | Up to 15 FPS |
| Point distance | 0.1-3 mm | 0.2-3 mm |
| Basic Accuracy | Up to 0.1 mm | |
| Volumetric Accuracy | Up to 0.25 mm/m | |
| Output formats | .stl, .obj, .ply, .asc, .igs, .txt, .mk2, .umk, and etc. | |
| Operating temperature range | -10℃–40℃ | |
| Interface mode | USB 3.0 | |
| Dimensions and weight | Dimensions: 140×94×258 mm; Weight: 856 g | |
| Power Source | INPUT：100-240VAC，50/60Hz/OUTPUT：24=3.75A，90W MAX | |
| Certificate | CE-EMC, CE-LVD, FCC, RoHS, EN 60825, EN 62471, WEEE | |
